| 型号 Type | 通 径 Nominal diameter | 尺寸(mm) Size(mm) | |||||
| D | D1 | 中D2 | L | H | H1 | ||
| MVD-A | 32 | 42.4 | 53 | 70 | 56 | 307 | 83 |
| 40 | 48.3 | 53 | 70 | 56 | 307 | 83 | |
| 50 | 60.3 | 65 | 78 | 60 | 389 | 81 | |
| 65 | 76.1 | 81 | 91 | 70 | 416 | 88 | |
| 80 | 88.9 | 99 | 132 | 91 | 450 | 81 | |
| 100 | 108 | 120 | 156 | 107 | 488 | 81 | |
| Technical Parameters | |
| Nominal Pressure(PN) | 2.5Mpa |
| Test Pressure (PS) | 4.0MPa |
| Supply Voltage | 24V |
| Applicable Temperature | -50°C~+150°C |
| Control Model | Digital ON/OFF signal |
| Modulatinganaloguesignal：0-10V | |
| Modulatinganaloguesignal：4-20mA | |
| PLC Control Bus | |
| Applicable Medium | Applicable to common nonflammable refrigerants including R717、R22( dependent on sealing material |
